LEM HAS 100-P Compact Current Transducer, 100A Nominal, PCB mounting, With Aperture
LEM USA Inc.

LEM HAS 100-P Compact Current Transducer, 100A Nominal, PCB mounting, With Aperture

Regular price Cdn $29.00 Cdn $0.00 Unit price per

Condition: New

Features

  • Hall effect measuring principle
  • Isolated plastic case recognized according to UL 94-V0
  • Advantages
  • Easy installation
  • Low power consumption
  • Small size and space saving
  • Only one design for wide current ratings range
  • High immunity to external interference

Applications

  • AC variable speed drives
  • Static converters for DC motor drives
  • Battery supplied applications
  • Uninterruptable Power Supplies (UPS)
  • Switched Mode Power Supplies (SMPS)
  • Power supplies for welding applications
Specifications
  • Series HAS
  • Measurement Current
  • Nominal Value 100 A
  • Measuring Range 300 A
  • Second. Nominal Signal Voltage
  • Second. Nominal Signal Value Instantaneous 4 V
  • Primary Signal AC + DC
  • Supply Voltage External DC Bipolar
  • Supply Voltage Range 15 - 15 V
  • Op. Temperature -10 °C / 80 °C
  • Technology Open loop Hall effect
  • Mounting PCB
  • For Measuring AC/DC
  • Sensor Type Hall Effect, Open Loop
  • Output Ratiometric, Voltage
  • Frequency DC ~ 50kHz
  • Linearity ±1%
  • Accuracy ±1%
  • Response Time 3µs
  • Current - Supply (Max) 15mA
  • Polarization Bidirectional
  • Mounting Type Through Hole
  • Number of Channels 1

Compliance

  • RoHS Status RoHS Compliant
  • Moisture Sensitivity Level (MSL) 1 (Unlimited)
  • REACH Status REACH Unaffected
  • ECCN EAR99
  • HTSUS 9030.33.3800
Cross Reference
  • 398-1043
  • HAS100P

For data sheet, click here.
