Omron M22N-BC-TWA-YC-P Cylindrical LED Lamp, 24 VAC/VDC Yellow
Omron M22N-BC-TWA-YC-P Cylindrical LED Lamp, 24 VAC/VDC Yellow
Regular price
$39.00 CAD
Regular price
Sale price
$39.00 CAD
FREE SHIPPING to Canada and USA! Please ask for shipping rates to other regions. All items ship from Toronto, Canada.
Quantity
Couldn't load pickup availability
FREE SHIPPING TO ANYWHERE IN USA OR CANADA INCLUDED!
Condition: New
Specifications
- Shape Cylindrical type (22/25 mm dia.)
- Lighted method LED lamp
- Terminal Push-In Plus Terminal Block
- Transparency/Opacity Transparent
- Lamp color Yellow
- Rated voltage 24 VAC/VDC
- Operating voltage 24 VAC/VDC±10%
- Rated current 12 mA
- Dielectric strength Between each terminaland ground: 2500 VAC 50/60 Hz 1 min
- (Initial value)
- Vibration resistance Malfunction: 10 to 55 Hz, 1.5 mm double amplitude
- Shock resistance Malfunction: 1,000 m/s2 max.
- Ambient temperature range Operating: -25 to 55 ℃ (with no freezing or condensation)
- Storage: -40 to 80 ℃ (with no freezing or condensation)
- Ambient humidity range Operating: 35 to 85% RH
- Degree of protection Front panele: IP66, NEMA4X, NEMA13
- Classification of protection against electric shock Class II
- PTI (Tracking characteristic) 175
- Pollution degree 3 (EN60947-5-1)
- Weight Approx. 30 g
