Square D
SquareD 9012 GRO-4 Industrial Pressure Switch (9012GRO4)
Regular price
$189.00
FREE SHIPPING TO ANYWHERE IN USA OR CANADA INCLUDED!
Condition: New
Specifications
- Pressure sensor type Electromechanical pressure switch
- Pressure Rating 75 psi (517.11 kPa)
- Maximum pressure 240 psi
- Contacts type and composition NC-NO, SPDT, Form C, snap action, silver nickel contacts
- Fluid connection type 1/4" inch 18 NPTF UL 508
- Range on decreasing pressure 1.5…75 psi (10.34…517.11 kPa)
- Cable entry 1/2" inch NPT conduit entrance
- Terminal block type 4 screw terminals
- Electrical connection Screw-clamp terminals, AWG 22...AWG 12
- Pressure actuator Diaphragm nitrile (Buna-N)
- Height 5.41 in (137.41 mm)
- Depth 2.46 in (62.48 mm)
- Width 2.06 in (52.32 mm)
- Materials in contact with fluid Nitrile (Buna-N)
- Maximum operating rate 120 cyc/mn
- Mechanical durability 5,000,000 cycles
- Standards
- CE, UL 508, CSA LR26817 class 3218 02, CSA LR25490 class 3211 03
- Ambient Air Temperature for Operation -10…185 °F (-23…85 °C)
